MaxHub Education Series

Maxhub Monitor & Wireless Presenter
MAXHUB  DISTRIBUTOR
MAXHUB COLLABORATION SOLUTION


MaxHub E-Series

MaxHub IFP E2-Series


MaxHub E2-Series Features



3 Years Standard Warranty



Contact or whatsapps for price
03-8069 1655/ 1755
012-278 5731
sales@3wiredsys.com

MAXHUB Collaboration Display


EDU Software Suite
MaxHub Connect Wireless Mirroring
MaxHub Pivot
MaxHub Class Tools
MaxHub OS
Screen Recording



Immersive Display for Learning
A display that focuses attention, and fuels interaction


E6520
E7520
E8620

Education Interactive Series
Diagonal Size (inch)
65"
75"
86"
Backlight | Panel Technology
Direct-lit LED | VA
Aspect ratio | Resolution
16:9 | 3840 x 2160
Response Time | Refresh Rate
8ms | 60Hz
Contrast Ratio | Brightness
1200:1 (Typ), 4000:1 (Dynamic)  |  380cd/m2
Glass Treatment | Thickness | Hardness
Anti-glare, Tempred | 3mm | 9H
Color Gamut | Bonding
72% NTSC | Zero parallax
Viewing Angle | Backlight Life
H178°/ V178°  |   >50,000 Hours
Color Accuracy | Color Depth
Delta E < 2 | 1.07B (10bit)
Eyes Care
TÜV Low Blue Light,  TÜV Flicker Free
Anti-bacterial
TÜV / SGS/ SIAA Certified | Stylus, Power Button

Touch System
Max Touch Points Supported
20 touch points (OS dependent)
Accuracy | Object Recognition Range
±1.5mm/>3mm
Touch Tool
Finger, Gesture, Stylus (Passive dual nibs)
Supported OS (Touch Return)
Windows 10,8,7,XP/ Android/ Linux/ Mac OS X/ Chrome OS

Built-in System
CPU
Android 11.0 - 2GHz quad core ARM A55, 4GB RAM, 32GB ROM, GPU Mali-G52 MP2

Connectivity
Input
3x HDMI 2.0 In
Type A: 4x USB 3.0, 1x USB 2.0
Multifunction Port 1x USB Type C
2x LAN Wired RJ45/ 1x WiFi 2.5GHz & 5GHz
1x Audio In
Output
1x HDMI Out (Up to 4K@60fps)
1x Audio Out, 1x S/PDIF Out
Control
1x RS232
OPS Slot | OPS Compatible
Yes, 3840x2160@60fps | OPS62A, 11th gen Intel i5/i7

Speaker
Built-in Speakers
2.0 channel, 2x 16W

Software
Screen Share
Yes
On Board Apps
Browser, Cloud Drive, System Keeper, Note, Palette, Annotate, Timer, Screen Recording, Split Screen, Screen Lock, etc.

Accessory
Cables
3m Power Cord, 1.4m HDMI, 5m USB Type A->B, 1.8m USB Type C
Others
Remote Control, Wall Mount Bracket, 2x Stylus, Wireless Adapter

Physical Specification
Dimension (W x H x D)
1488.1 x 896.3 x 88.3 mm
1709.1 x 1019.9 x 87.6 mm
1956.7 x 1159.7 x 99.6 mm
Gross Dimension (W x H x D)
1628 x 1024 x 208 mm
1863 x 1140 x 225 mm
2110 x 1283 x 225 mm
VESA
600 x 400 mm,
M8 x 25mm
800 x 600 mm,
M8 x 25mm
800 x 600 mm,
M8 x 25mm
Net Weight | Gross Weight
35.50kg | 45.80kg
47.90kg | 61.65kg
60.10kg | 77kg

Datasheet
Brochure
E6520
E7520
E8620
