HDMI HDBaseT Wall Panel Multi-Input Transmitter

HDMI HDBaseT Wall Plate Extender

PRODUCT FEATURES DIAGRAM DATA SHEET

HDMI/ IR HDBaseT Wall Plate Extender Support up to 100m EVBMR-MA110W per pair RM 2,352.00 EVBMR-A110WL (Transmitter) RM 1,190.00 EVBMR-A110WR (Receiver) RM 1,162.00 Support up to 70m EVBMR-MA107W per pair RM 1,722.00 EVBMR-A107WL (Transmitter) RM 882.00 EVBMR-A107WR (Receiver) RM 840.00		TRANSMITTER (L)	RECEIVER (R)
	MODEL	EVBMR-A110WL (100m) EVBMR-A107WL (70m)	EVBMR-A110WR (100m) EVBMR-A107WR (70m)
	INPUT PORT	HDMI/ IR
	OUTPUT PORT		HDMI/ IR
	CONNECTION	RJ45 HDBT/ IR
	IR EXTENSION	Bi-Drection IR Transceiver/ IR Receiver
	DISTANCE SUPPORT	HDMI 70m @Full HD 1920x1080 35m @UHD 3840x2160	HDMI 100m @Full HD 1920x1080 70m @UHD 3840x2160
	POWER SUPPLY	DC 12V Phamom Power - Single power supply at either end
	Use 24AWG solid cable without cascade. STP cabling is recommended for environment with high EMI or RFI for best performance results. Avoid using stranded, thinner and excess coiling cables.

HDMI/ IR Wall Plate HDBaseT Extender

TRANSMITTER

EVBMR-MA110WW (100m)

EVBMR-MA107WW (70m)

Transmit HDMI/ IR signal up to 70 / 100 meters
Uses HDBaseT technology
Remote EDID Copy Ensures Optimum Video performance
Bi-Directional IR Extension
Use Resolution Alternation Mode when catching multiple similar video timing
Input source sequence selecable
Auto-sensing function enables the system to automatically select the lastest video source
Support resolutions up to UHD (3840 x 2160) and Full HD (1920 x 1080) and compatible with most of the popular screen resolution
HDCP compliant, 3D-video and Blu-ray ready over single CATx cable
Plug-and-Play system without any drivers or software installation

EVBMR-MA110WW/ MA107WW

HDMI HDBaseT Wall Plate Transmitter

PRODUCT FEATURES DIAGRAM DATA SHEET

HDMI/ VGA/ AUDIO HDBaseT Wall Plate Switch Transmitter EVBMV-A1371WL RM 1,932.00 support up to 70m EVBMV-A1391WL RM 2,352.00 support up to 100m		TRANSMITTER (TX)
	MODEL	EVBMV-A1371WL	EVBMV-A1391WL
	INPUT PORT	2x HDMI, VGA, Analog Stereo
	OUTPUT PORT	HDMI Local
	CONNECTION	RJ45
	LED (Link/ Video Status)	1x Remote LED/ 1x Local LED/ 3x Source LED
	VIDEO RESOLUTION (max)	VGA: Full HD 19280x1080 HDMI/ DP: 4K2K UHD 3840x2160
	DISTANCE SUPPORT	HDMI 70m @Full HD 1920x1080 35m @UHD 3840x2160 VGA 70m @Full HD 19280x1080	HDMI 100m @Full HD 1920x1080 70m @UHD 3840x2160 VGA 100m @Full HD 19280x1080
	PUSH BUTTON	Select, Alt \| EDID Copy (under the cover)
	MODE CONFIGURATION	Switch/ Auto/ Pri-A/ Pri-B
	SERIAL CONTROL	RJ-12
	POWER SUPPLY	DC 12V
	Use 24AWG solid cable without cascade. STP cabling is recommended for environment with high EMI or RFI for best performance results. Avoid using stranded, thinner and excess coiling cables.

HDMI + VGA + Audio Wall Plate Switch over HDBaseT Transmitter

TRANSMITTER

EVBMV-A1391WL (100m)

EVBMC-A1371WL (70m)

Transmit HDMI / VGA with analog audio signal up to 70 / 100 meters
Uses HDBaseTTM technology
Auto EQ (Sharpness) adjustment for optimal signal clarity
Screen Shift Mode provides user to adjust image's shifting
Use Resolution Alternation Mode when catching multiple similar video timing
Input source sequence selecable
Auto-sensing function enables the system to automatically select the lastest video source
Support resolutions up to UHD (3840 x 2160) and Full HD (1920 x 1080) and compatible with most of the popular screen resolution
HDCP compliant, 3D-video and Blu-ray ready over single CATx cable
Plug-and-Play system without any drivers or software installation

EVBMV-A1371WL/ 1391WL
